Система охлаждения/RADIATOR - OIL COOLER AND FITTINGS (S/N: A80001-) H1-1-1 Hidromek HMK 102 S

1. COOLER
2. 020/40076 COWLING, FAN
3. N03/0020111 WASHER
4. N01/0232078 BOLT M8x16
5. N01/0232462 BOLT M10x25
6. N03/0020018 WASHER M10
7. 020/21088 RING
8. 810/40006 GROMMET
9. 020/03015 BRACKET MOUNTING
10. N01/0232438 BOLT M10x20
11. N03/0020121 WASHER
12. 020/03189 AIR CURTAIN
13. N01/0232054 BOLT M8x12
14. H13/0133015 STRIP 1,81m
15. 806/08014 ADAPTER
16. 020/12804 AIR CURTAIN, RIGHT
17. 020/12805 AIR CURTAIN, LEFT
18. N01/0231442 BOLT M6x10
19. N03/0100013 WASHER, M6
21. H06/7000104 HOSE 0,25m
22. F99/29009 EXPANSION TANK
23. F99/00760 EXPANSION TANK COVER
24. 020/11554 CLAMP
25. 810/48118 RUBBER CLAMP
26. 810/48117 RUBBER CLAMP
27. N01/0232114 BOLT M8x30
28. N03/0020011 WASHER, M8
29. N02/5910062 NUT M8
30. 019/92996 BRACKET
31. N07/7002426 HOSE, HOLDER
32. N07/4010016 CLAMP
33. N07/4050070 CLAMP
34. 810/40528 HOSE
35. 810/40502 HOSE
36. N03/0020111 WASHER
37. N02/5910086 NUT M10
38. N07/4016025 CLAMP
39. H13/4200800 INSULATION, HOSE 0,4m
40. N07/4405779 CLAMP
41. F99/06193 HOSE
42. N07/4404567 CLAMP
43. 810/09539 PIPE
44. N01/0232138 BOLT M8x25
45. F99/06192 HOSE
46. 810/09537 PIPE
47. 810/09538 PIPE
48. F99/06191 HOSE
49. 663/112G100 HOSE
50. 701/332M235 HOSE
51. N07/4016025 CLAMP
52. 510/12200 CIRCLIP
53. H13/4200800 INSULATION, HOSE 0,5m
54. H13/0315150 BAND 0,56m
55. H13/0315150 BAND 0,56m
56. N01/0232078 BOLT M8x16
57. N01/0232438 BOLT M10x20
58. N03/0020121 WASHER
59. H06/7000104 HOSE 1,05m
60. N03/0810014 WASHER
61. 816/02044 SEAL INSULATION
62. 816/02044 SEAL INSULATION
63. N16/3470450 ELBOW
64. N01/0232114 BOLT M8x20
65. N03/0020011 WASHER

Характеристики
Применяемость	102S
